Pre-Authorization (Israel)

Tweezercomm's pre-authorization transactions are processed, authorized, and either settled or canceled based on the response from the payment server. This process also includes a resilience mechanism for handling errors.

Transaction Flow

To understand the pre-authorization transaction flow, consider the following sequence of events:

Here's a breakdown of each step:

1. The client application (POS) sends a [doTransaction()\](doc:dotransaction-ashrait) request to the Nayax Device with a parameter (Trancode=2) to initiate a pre-authorization.
2. The cardholder inserts, shows, or swipes their card.
3. The Nayax Device communicates with the payment server to perform the pre-authorization.
4. The payment server responds, and the Nayax Device relays the Authorization result back to the POS.
5. At a later time, the POS sends another doTransaction() request, this time with a parameter (Trancode=3) to initiate the completion of the pre-authorized transaction.
6. The Nayax Device communicates with the payment server to complete the transaction.
7. The payment server responds with a Completion result, which the Nayax Device sends back to the POS.
8. At the end of the day, the POS sends a doPeriodic() request. The Nayax Device communicates with the payment server to perform the settlement of the day's transactions and sends adoPeriodic() result back to the POS.
