Payment Flows
The Nayax Marshall SDK supports various payment flows, each catering to specific operational needs. These dictate how the system handles vending sessions, payment authorizations, and transaction processing.
Recommended Flow and Configuration
The table below provides the recommended flow depending on the machine type.
| Machine Type | Recommended Flow | Recommended Configuration |
|---|---|---|
| Vending Machine | Single Session + Pre-Selection | Always Idle |
| Coin Exchanger | Single Session + Pre-Selection | Always Idle |
| Cotton Candy | Single Session + Pre-Selection | Always Idle + Explicit Vend Success |
| Photo Booth | Single Session + Pre-Selection | Always Idle |
| Coffee Machine | Single Session + Pre-Selection | Always Idle |
| Massage Chair | Single Session + Pre-Selection | Always Idle |
| Car Washing Machine | Single Session + Pre-Selection | Always Idle |
| EV Charger 1 | Multi Session | Price not final |
| EV Charger 2 | Multi Session | Price not final + Mifare approved by VMC |
| EV Charger 3 | Multi Session | Price not final + Mifare approved by VMC + Info Session |
| EV Charger 4 | Multi Session | Price not final + Mifare approved by VMC + Info Session + Always On |
| Smart Fridge | Multi Session | Price not final + Always On |
| Power Bank | Multi Session | Price not final + Always On |
| Locker | Multi Session | Price not final |
| Racket Rental Machine | Multi Session | Price not final + Always Idle |
Supported Flows
Below are all the supported payment flows by Marshall:
